JVC UX-A52R Service Manual

UX-A52R
UX-A52R
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 GV10076-016A
FRONT PANEL
1
2 GV10077-001A
SUB FRAME
1
3 GV10078-001A
MAIN FRAME
1
4 QYSBSF2008Z
SCREW 4
FRONT PNL+MAIN
5 GV40190-001A
CONTROL BUTTON
1
6 QYSBSF2608Z
T.SCREW 2
FRONT+CONT.BTN
7 QYSBSF2608Z
T.SCREW
1
+ FRONT PANEL
8 QYSBSF2608Z
T.SCREW
1
FRONT+E.BTN.B
9 GV40197-001A
EJECT BUTTON A
1
10 GV40198-001A
EJECT BUTTON B
1
12 QYSBSF2608Z
T.SCREW
4
FRONT+ GEAR ASS
13 GV40200-002A
PANEL HOLDER L
1
14 GV40201-002A
PANEL HOLDER R
1
15 GV20131-002A
FRONT CASE
1
16 GV30207-001A
LED LENS
1
17 QYSBSF2608Z
T.SCREW
1
LED LENS+FRONT
18 GV40217-001A
SPACER
1
19 GV40217-002A
SPACER
1
20 GV40210-001A
LCD LENS
1
21 GV30206-001A
LCD HOLDER
1
22 GV40221-001A
LCD SHEET 1
23 GV40202-001A
LED HOLDER
1
24 GV40203-002A
LED HOLDER B 1
25 GV30208-002A
LED COVER
1
26 GV30213-002A
LCD COVER
1
27 GV20132-002A
FRONT LENS
1
28 QYSBSF2610Z
SCREW 4
LCD COVER+F.CAS
29 QYSDSF2006N
SCREW
4
F.LENS+ F.CASE
30 QYSBSF2608Z
T.SCREW 2
CON.PWB+ F.PANE
31 GV40035-001A
SPECIAL SCREW
2
F.PANEL+PANEL H
32 GV40219-001A
SPECIAL SCREW
1
DETEC.SW.PWB+F.
33 GV40199-001A
ROLLER 2
34 GV40214-001A
FRONT SPRING
1
35 QYSBSF2608Z
T.SCREW
1
F.SPRING/F.BRD
36 GV40235-003A
SPACER
1
37 GV40243-001A
SPACER 1
STICK AT LCD HO
38 GV40242-003A
COMMON SPACER
1
MOV.PNL/PHONE W
39 GV40242-004A
COMMON SPACER
2
WIRE ARRANG.
40 GV10081-002A
BOTTOM CHASSIS
1
41 GV40195-001A
CD MECHA BRACKE
1
42 QYSBST3004Z
T.SCREW
2
CD M.BKT+BTM.CH
43 QYSBST3008Z
T.SCREW 3
CD MECHA+BTM.CH
44 QYSBST4006Z
T.SCREW
4
TRANS +BTM.CHAS
45 QYSBST3006Z
T.SCREW 1
BKT.+ AC PWB.
46 GV40247-001A
SPACER
1
47 ---------------
CD MECHA
1
48 GV10080-001A
INNER CHASSIS
1
49 QYSBST3006Z
T.SCREW 4
INNER CHA+ BTTM
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
50 QYSBST3006Z
T.SCREW
1
TUNER PWB+ BTTM
51 QYSBST3006Z
T.SCREW
1
FMB PWB+BTM.CHA
52 QYSBSF3010N
TAP SCREW
1
TUNER+BTM.CHAS(
53 QYSBSF3010Z
SCREW 1
CHASSIS+MECH.BR
54 GV30201-002A
IC HOLDER
1
55 GV30203-001A
HEAT SINK 1
56 QYSBSF3012Z
SCREW
3
IC HOLD.+ H.SIN
57 GV20153-002A
MECHA BRACKET
1
58 QYSBSF3010Z
SCREW
4
CASS.MEC/IN.CHA
59 QYSBSF3008Z
SCREW
4
CASS./MECH.BRAC
60 GV40242-004A
COMMON SPACER
1
FOR HEAD SHIELD
61 E310243-002
PLASTIC RIVET
1
PHONE PWB+BTTM.
62 QYSBSF3010Z
SCREW
1
AC PWB+INNER CH
63 QWTBG00-130
VINYL TUBE
1
64 QWTBG00-040
VINYL TUBE
1
65 QYSBSF3008Z
SCREW
2
MAIN BRD/BRACKE
66 GV40251-002A
SPACER
1
STICK AT BTM.CH
67 GV40259-001A
PROTECT SHEET
1
(MICOM)
68 GV40240-001A
PROTECT SHT(AC)
1
(SUB TRANS.)
69 GV40242-003A
COMMON SPACER
1
FOR EMC USED
70 GV10089-001A
TOP COVER(EXP) 1
71 GV30197-002A
BOTTON
1
72 QYSBSF2608Z
T.SCREW 7
BUTTON+TOP COVE
73 QYSSST3010Z
SCREW
2
F.PNL/BTTM CHAS
74 QYSBSF3008Z
SCREW
2
F.PANEL/T.COVER
75 GV40091-002A
FOOT
4
FRONT & REAR
76 GV30233-001A
HEAD SHIELD 1
77 GV30234-001A
SLC COVER
1
78 QYSDST3004Z
SCREW 2
FOR HEAD SHIELD
79 GV10082-002A
SIDE PANEL(L)
1
80 GV10083-006A
SIDE PANEL(R)
1
81 GV10085-008A
REAR COVER 1
82 QYSBSF3010N
TAP SCREW
7
FOR REAR COVER
83 QYSSST3010Z
SCREW
2
+ REAR COVER
84 GV30200-002A
CD FITTING
1
85 GV30226-006A
RATING LABEL 1
86 VND4118-003
CAUTION LABEL
1
STICK AT R.COVE
87 BDL1141-001M
C MECHA UNIT
1
CASSETTE MECHA
89 E406507-001
LASER CAUTION
1
93 GV40250-001A
BOARD SPACER
1
STICK AT FMB BO
94 QQT0360-002
POWER TRANSF
A
1
T1001
95 QUQ412-1330CJ
FFC WIRE 1
FMB-TUNER
96 QUQ610-1415BF
FFC WIRE
1
CONN-LCD
97 QUQ110-1915BJ
FFC WIRE
1
FMB-CD
98 QUQ412-0510DJ
FFC WIRE
1
FMB-FKEY
99 QJA003-132520
WIRE 1
FW803
100 QJA003-051700
SIN ID C-C WIRE
1
FW802
101 WJN0074-001A
E-SH C WIRE C-C 1
FW801
