JVC UX-A52R Service Manual

UX-A52R
3-10
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
BZ201 QAN0045-001 BUZZER SOUNDER
CN801 QGB2510K2-12 CONNECTOR
CN802 QGB2510K2-12 CONNECTOR
CN803 QGA3901C1-04 CONNECTOR
CN804 QGA2501C1-05 5P CONNECTOR
CN805 QGB2510J1-04 CONNECTOR
CN808 QGB2510K2-04 CONNECTOR
CN809 QGA7901C1-02 CONNECTOR
CN905 QGF1201F3-05 CONNECTOR
CN906 QGD2504C1-04Z SOCKET TO FUNCTION KEY
CN907 QGA2501F1-02 CONNECTOR
CN908 QGF1016F1-14 FFC/FPC CONNE TO CONN. BOARD
CN909 QGB2024J1-20S B TO B CONNE
C1001 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1002 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1003 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1004 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1005 QETM1EM-228 E CAPACITOR 2200MF 20% 25V
C1006 QETM1EM-228 E CAPACITOR 2200MF 20% 25V
C1007 QETM1EM-108 E CAPACITOR 1000MF 20% 25V
C1008 QCZ9105-472 C CAPACITOR
A
4700PF
C1009 QCFB1HZ-105Y C CAPACITOR 1.0MF +80:-20%
C1014 QFLA1HJ-104Z M CAPACITOR .10MF 5% 50V
C1015 QFLA1HJ-104Z M CAPACITOR .10MF 5% 50V
C1016 QFLA1HJ-104Z M CAPACITOR .10MF 5% 50V
C1017 QFLA1HJ-104Z M CAPACITOR .10MF 5% 50V
C1018 QEZ0512-828 E CAPACITOR
A
8200MF
C1042 QETC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1043 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1046 QETN1HM-336Z E CAPACITOR 33MF 20% 50V
C1047 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C1052 EETC1HM-105ZJC E CAPACITOR
C1053 EETC1HM-105ZJC E CAPACITOR
C1054 QFLC1HJ-563Z M CAPACITOR .056MF 5% 50V
C1055 QFLC1HJ-563Z M CAPACITOR .056MF 5% 50V
C1056 QFLA1HJ-104Z M CAPACITOR .10MF 5% 50V
C1058 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C1105 QTE1V06-106Z E CAPACITOR
C1106 QDGB1HK-102Y C CAPACITOR
C1107 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1108 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1109 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1110 QCBB1HK-221Y C CAPACITOR EMC
C1111 QDXB1CM-332Y C CAPACITOR EMC
C1205 QTE1V06-106Z E CAPACITOR
C1206 QDGB1HK-102Y C CAPACITOR
C1207 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1208 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1209 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1210 QCBB1HK-221Y C CAPACITOR EMC
C1211 QDXB1CM-332Y C CAPACITOR EMC
C1301 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1302 QDGB1HK-102Y C CAPACITOR
C1401 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1402 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C1501 EETC1CM-107ZJC E CAPACITOR
C1502 QCFB1HZ-105Y C CAPACITOR 1.0MF +80:-20%
C1601 EETC1CM-107ZJC E CAPACITOR
C1602 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%
C1701 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1704 QDGB1HK-102Y C CAPACITOR
C1705 QDGB1HK-102Y C CAPACITOR
C1706 QENC1HM-106Z NP E CAPACITOR 10MF 20% 50V
C1707 QENC1HM-106Z NP E CAPACITOR 10MF 20% 50V
C1709 QCBB1HK-103Y C CAPACITOR
C1710 QETN1EM-337Z E CAPACITOR 330MF 20% 25V
C1801 QDYB1CM-103Y C CAPACITOR
C1802 EETC1EM-476ZJC E CAPACITOR
C1803 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1901 EETC1CM-107ZJC E CAPACITOR
C1902 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%
C1908 QCFB1HZ-105Y C CAPACITOR 1.0MF +80:-20%
D1001 1N5401-TM DIODE
A
D1002 1N5401-TM DIODE
A
D1003 1N5401-TM DIODE
A
D1004 1N5401-TM DIODE
A
D1005 1N5401-TM DIODE
D1006 1N4003S-T5 SI DIODE
D1007 1SS133-T2 SI DIODE
D1008 1SS133-T2 SI DIODE
D1012 1N5401-TM DIODE
A
D1013 1N5401-TM DIODE
A
D1014 1N5401-TM DIODE
A
D1015 1N5401-TM DIODE
A
D1026 1SS133-T2 SI DIODE
D1027 1SS133-T2 SI DIODE
D1301 MTZJ11A-T2 ZENER DIODE
D1401 MTZJ8.2B-T2 DIODE
D1402 1SS133-T2 SI DIODE
D1403 1SS133-T2 SI DIODE
D1404 1SS133-T2 SI DIODE
D1405 1SS133-T2 SI DIODE
D1501 MTZJ8.2C-T2 ZENER DIODE
D1601 MTZJ8.2C-T2 ZENER DIODE
D1603 MTZJ5.6B-T2 ZENER DIODE
D1604 1SS133-T2 SI DIODE
D1605 1SS133-T2 SI DIODE
D1606 1SS133-T2 SI DIODE
D1701 MTZJ5.6B-T2 ZENER DIODE
D1703 1SS133-T2 SI DIODE
D1801 MTZJ13B-T2 Z DIODE
D1901 MTZJ10C-T2 Z.DIODE
D1902 1SS133-T2 SI DIODE
D1903 1SS133-T2 SI DIODE
D1904 1SS133-T2 SI DIODE
D1905 1SS133-T2 SI DIODE
FW906 QUM024-10DGZ3 PARA RIBON WIRE TO CONN BOARD
IC801 LA4628 IC
A
IC802 L4909 REGULATOR IC
IC803 KIA78S05P-T IC SW5V REG
J1001 QNB0133-001 SPK TERMINAL
J1002 QNS0030-001 JACK
J1003 QNC0006-001 AC SOCKET
A
K1002 QQR0621-001Z FERRITE BEADS EMC
K1003 QUY150-050Y BUS WIRE EMC
K1004 QQR0621-001Z FERRITE BEADS EMC
K1005 QQR0621-001Z FERRITE BEADS EMC
K1006 QUY150-050Y BUS WIRE EMC
K1009 QQR0779-001Z INDUCTOR EMC
K1010 QQR0779-001Z INDUCTOR EMC
L1003 QQL231K-470Y INDUCTOR EMC
L1004 QQL231K-470Y INDUCTOR EMC
L1005 QQL231K-470Y INDUCTOR EMC
L1006 QQR1145-001 LINE FILTER EMC FILTER
L1101 QQR0797-001 INDUCTOR EMC
L1201 QQR0797-001 INDUCTOR EMC
Item
Parts number Parts name Ar
e
a
Remarks
A
