JVC UX-G3 Service Manual

3-23
CD board
Block No. [0][4]
R740 OW390100126102 C RESISTOR 1K Ω 1/16W
R741 OW390270126106 C RESISTOR 2.7K
Ω 1/16W
R742 OW390100226108 C RESISTOR 10K
Ω 1/16W
R743 OW390100226108 C RESISTOR 10K
Ω 1/16W
R744 OW390100226108 C RESISTOR 10K
Ω 1/16W
R745 OW390100226108 C RESISTOR 10K
Ω 1/16W
R746 OW390100226108 C RESISTOR 10K
Ω 1/16W
R747 OW390100226108 C RESISTOR 10K
Ω 1/16W
R748 OW390100226108 C RESISTOR 10K
Ω 1/16W
R749 OW390100226108 C RESISTOR 10K
Ω 1/16W
R750 OW390100226108 C RESISTOR 10K
Ω 1/16W
R751 OW390100226108 C RESISTOR 10K
Ω 1/16W
R752 OW390100226108 C RESISTOR 10K
Ω 1/16W
R753 OW390100226108 C RESISTOR 10K
Ω 1/16W
G3_UB,
G3_UP,G
3_US,G3
_UT,G3_
UW,G3_
UY
R753 OW390470026106 C RESISTOR 470
Ω 1/16W
G4_A,G4
_UB,G4_
US,G4_U
T, G 4 _U
W
R754 OW390910126103 C RESISTOR 9.1K
Ω 1/16W
R755 OW390270126106 C RESISTOR 2.7K
Ω 1/16W
R756 OW390390126108 C RESISTOR 3.9K
Ω 1/16W
R757 OW390560226108 C RESISTOR 56K
Ω 1/16W
R758 OW390750926107 C RESISTOR 75 1/16W
R759 OW390470026106 C RESISTOR 470
Ω 1/16W
R760 OW390150126104 C RESISTOR 1.5K
Ω 1/16W
R761 OW390360126105 C RESISTOR 3.6K
Ω 1/16W
R762 OW390180126107 C RESISTOR 1.8K
Ω 1/16W
R763 OW390560226108 C RESISTOR 56K
Ω 1/16W
R764 OW390100226108 C RESISTOR 10K
Ω 1/16W
R765 OW390680126104 C RESISTOR 6.8K
Ω 1/16W
R766 OW390470126103 C RESISTOR 4.7K
Ω 1/16W
R780 OW390100126102 C RESISTOR 1K
Ω 1/16W
R781 OW390000029121 C RESISTOR 0
Ω 1/16W
R782 OW390100126102 C RESISTOR 1K
Ω 1/16W
R788 OW390100226108 C RESISTOR 10K
Ω 1/16W
L701 OW162070102064 COIL 100uH
L702 OW162070102064 COIL 100uH
L706 OW162070102075 COIL 100uH
CN701 OW261041082272
CONNECTOR
WIRE
8P for MAIN CN103
CN702 OW261041082248
CONNECTOR
WIRE
8P for MAIN CN303
CN703 OW261041032238
CONNECTOR
WIRE
3P for CD CN603
CN704 OW261041072206
CONNECTOR
WIRE
7P for MAIN CN203
CN706 OW261041102143
CONNECTOR
WIRE
10P for CD CN606
CN707 OW261042021315
CONNECTOR
WIRE
2P for MAIN CN481
CN708 OW261041021365
CONNECTOR
WIRE
2P for CD door
switch
J730 OW390000049315 C RESISTOR 0
Ω 1/8W
J731 OW390000049315 C RESISTOR 0
Ω 1/8W
J732 OW390000049315 C RESISTOR 0
Ω 1/8W
J733 OW390000049315 C RESISTOR 0
Ω 1/8W
J734 OW390000049315 C RESISTOR 0
Ω 1/8W
J735 OW390000049315 C RESISTOR 0
Ω 1/8W
J736 OW390000049315 C RESISTOR 0
Ω 1/8W
J737 OW390000049315 C RESISTOR 0
Ω 1/8W
J739 OW390000049315 C RESISTOR 0
Ω 1/8W
J740 OW390000049315 C RESISTOR 0
Ω 1/8W
J741 OW390000049315 C RESISTOR 0
Ω 1/8W
J742 OW390000049315 C RESISTOR 0
Ω 1/8W
J743 OW390000049315 C RESISTOR 0
Ω 1/8W
J744 OW390000049315 C RESISTOR 0
Ω 1/8W
J745 OW390000049315 C RESISTOR 0
Ω 1/8W
RV701 OW254092040043 ENCODER VOL
EC162102 FIB-
HA1-24
SEN701 OW309062638005 SENSOR IRM2638F4
SW701 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
 Symbol No. Part No. Part Name Description Local
SW702 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW703 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW704 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW705 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW706 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW707 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW708 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW709 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW710 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
X701 OW156050720026 CER. RESONATOR ZTA7.2MT
X702 OW290032768078 CRYSTAL 32.768MHz 20PPM
XXXXX OW169004344028 FERRITE CORE for CN707
XXXXX OW235020080029 WIRE
for PGND2 to CD
P4
XXXXX OW603000003022 CABLE TIE 4UL(x2)
XXXXX OW603000005029 CABLE TIE 6.5UL(x2)
 Z702 8.2V0.5W Z DIODE OW303050082024
 Symbol No. Part No. Part Name Description Local
IC601 TC94A14FA CD LSI IC OW510009414017
IC602 TA2157FN IC OW510002157016
IC603 TA2092AN IC OW510002092038
IC604 TC94A02F-007 IC OW510009402012
IC605 AS7C31024B-15 IC OW510031024039
IC606 SN74HC14DR IC OW510007414038
 IC607 PJ7805 IC OW510007805103
Q601 8050 TRANSISTOR OW343008050075
Q602 8050 TRANSISTOR OW343008050075
Q603 8050 TRANSISTOR OW343008050075
Q604 8050 TRANSISTOR OW343008050075
Q605 2SA733PNP TRANSISTOR OW343000733056
Q608 8050 TRANSISTOR OW343008050064
D601 1N4148 DIODE OW300004148083
C600 OW120102526009 C CAPACITOR 1000pF 50V
C601 OW131222012908 E CAPACITOR 220uF 10V
C602 OW131471012902 E CAPACITOR 47uF 10V
C603 OW131471022911 E CAPACITOR 47uF 16V
C604 OW131471022911 E CAPACITOR 47uF 16V
C605 OW131471022911 E CAPACITOR 47uF 16V
C606 OW131471022911 E CAPACITOR 47uF 16V
C607 OW131472012907 E CAPACITOR 470uF 10V
C608 OW120104527009 C CAPACITOR 0.1uF 50V
C609 OW131222012908 E CAPACITOR 220uF 10V
C610 OW120104527009 C CAPACITOR 0.1uF 50V
C611 OW120104527009 C CAPACITOR 0.1uF 50V
 C612 OW131103012902 E CAPACITOR 1000uF 10V
C613 OW120104527009 C CAPACITOR 0.1uF 50V
C614 OW120473527005 C CAPACITOR 0.047uF 50V
C620 OW131472012907 E CAPACITOR 470uF 10V
C621 OW120104527009 C CAPACITOR 0.1uF 50V
C622 OW131102022904 E CAPACITOR 100uF 16V
C623 OW120030526008 C CAPACITOR 3 pF 50V
C624 OW120104527009 C CAPACITOR 0.1uF 50V
C625 OW120104527009 C CAPACITOR 0.1uF 50V
C626 OW120680526001 C CAPACITOR 68pF 50V
C627 OW120393527001 C CAPACITOR 0.039uF 50V
C628 OW120104527009 C CAPACITOR 0.1uF 50V
C629 OW120104527009 C CAPACITOR 0.1uF 50V
C630 OW120472527009 C CAPACITOR 4700pF 50V
C631 OW120470526009 C CAPACITOR 47pF 50V
 Symbol No. Part No. Part Name Description Local
