JVC UX-G3 Service Manual

3-25
R6102 OW390220026107 C RESISTOR 220 Ω 1/16W
R6103 OW390220026107 C RESISTOR 220
Ω 1/16W
R6110 OW390100326105 C RESISTOR 100K
Ω 1/16W
R6111 OW390100326105 C RESISTOR 100K
Ω 1/16W
R6171 OW390000029121 C RESISTOR 0
Ω 1/16W
R6181 OW390000029121 C RESISTOR 0
Ω 1/16W
L601 OW168001122012 FERRITE BEAD RH03509ST-B246
L602 OW168001122012 FERRITE BEAD RH03509ST-B246
L603 OW162070471036 COIL 47uH
L604 OW162070471036 COIL 47uH
L605 OW162070471036 COIL 47uH
L606 OW380100023318 C RESISTOR 100
Ω 1/8W
L607 OW162070471047 COIL 47uH
L608 OW162070471036 COIL 47uH
L609 OW162070471036 COIL 47uH
L610 OW162070471036 COIL 47uH
L611 OW162070101054 AXIAL INDUCTOR 10uH
L613 OW168001122012 FERRITE BEAD RH03509ST-B246
L614 OW168001122012 FERRITE BEAD RH03509ST-B246
CN601 OW238080160124 HEADER 16P
CN602 OW261041061355 CONNECTOR WIRE 6P for CD MECH
CN603 OW260021030017 HEADER 3P
CN604 OW261041032295 CONNECTOR WIRE 3P for MAIN CN602
CN605 OW261032032006 CONNECTOR WIRE 3P for MAIN CN603
CN606 OW260021100011 HEADER 10P
J601 OW390000049315 C RESISTOR 0
Ω 1/8W
J605 OW390000029121 C RESISTOR 0
Ω 1/16W
J606 OW390000049315 C RESISTOR 0
Ω 1/8W
J607 OW390000049315 C RESISTOR 0
Ω 1/8W
J608 OW390000049315 C RESISTOR 0
Ω 1/8W
J614 OW390000049315 C RESISTOR 0
Ω 1/8W
J615 OW390000049315 C RESISTOR 0
Ω 1/8W
J625 OW390000049315 C RESISTOR 0
Ω 1/8W
J630 OW390000049315 C RESISTOR 0
Ω 1/8W
J635 OW390000049315 C RESISTOR 0
Ω 1/8W
J642 OW390000049315 C RESISTOR 0
Ω 1/8W
J656 OW390000049315 C RESISTOR 0
Ω 1/8W
J657 OW390000049315 C RESISTOR 0
Ω 1/8W
J670 OW390000049315 C RESISTOR 0
Ω 1/8W
J671 OW390470026106 C RESISTOR 470
Ω 1/16W
J672 OW390000049315 C RESISTOR 0
Ω 1/8W
J674 OW390000049315 C RESISTOR 0
Ω 1/8W
P1 OW235050040011 WIRE 40mm BLK
X601 OW156051693083 CER. RESONATOR 16.9344MHz
XXXXX OW239061090007 CABLE
16P for CD PickUp
to CN601
XXXXX OW169004344028 FERRITE CORE For CD Audio
XXXXX OW169004344074 FERRITE CORE For CD Power
XXXXX OW672000013014 HEAT SINK For IC603
XXXXX OW672009025021 HEAT SINK For IC607
XXXXX OW235020060024 WIRE
for CD P3 to CD
MECH
 ZD601 3.9V0.5W Z DIODE OW303050039062
 ZD602 3.3V0.5W Z DIODE OW303050033068
 ZD603 3.3V0.5W Z DIODE OW303050033068
 ZD604 3.9V0.5W Z DIODE OW303050039062
 Symbol No. Part No. Part Name Description Local
