10.79
Ø 155
Ø 124.4
Ø 6
68.15
47.5
24.73
24.73
64.4264.42
3/4" – NPT
3/4" – NPT
27
65
112.7
Ø 155
5.0
10.0
82.5
92.5
Ø 126
R47.5
105.8
55.9
56
69 125
14
VN-T16U VN-T216U VN-T216VPRU
Operational Specifications
Image Device 1/2.7-type Megapixel CMOS sensor
Sync System Internal
Sensitivity Color: 0.3 lx, B/W: 0.3 lx (25% F1.2)
Day/Night Easy D/N True D/N
IR-LED – 21 LEDs, 15 m
Auto Gain Control Off/On, selectable
White Balance ATW (2800K – 8500K) and Manual
Electric Shutter PAL: 1/25 – 1/10000 sec. NTSC: 1/30 – 1/10000 sec
Noise Reduction Yes
3 Axis Gimbals – Yes
Motion Detection Yes
Lens Type
Optional
(1/3-type CS mount with easy back focus adjustment)
1/3-type 3-9mm, F:1.2 1/3-type 3-9mm, F:1.2 IR cut filter built-in
BLC Yes
Audio Line In/Out
Alarm 1 In / 1 Out (Alarm out spec: 0.5A / AC 120V max)
IP Specifications
Video Compression H.264 & MPEG4 & MJPEG
Video Streaming
Real time stream:1080P H.264 or 720P H.264+D1 or D1+D1
Independent controllable frame rate and bandwidth. Constant or variable bit-rate control
Resolution
PAL: 1080P (1920 x 1080), 720P (1280 x 720), D1 (720 x 576), 4CIF (704 x 576), VGA (640 x 480), CIF (352 x 288), QVGA (320 x 240)
NTSC: 1080P (1920 x 1080), 720P (1280 x 720), D1 (720 x 480), 4CIF (704 x 480), VGA (640 x 480), CIF (352 x 240), QVGA (320 x 240)
Image Frame Rate PAL: Up to 25fps NTSC: Up to 30fps
Security Multiple user access levels with password protection
Users 1 Administrator, 5 users
Video Access from Web Browser Full control of all camera settings available to administrator
Minimum Web Browsing Requirements
OS: Windows XP or Windows 7 Browser: Internet Explorer Version 6.0 to 8.0,
CPU: Intel Pentium IV X2 2.4 GHz or equivalent AMD, Memory: 1G or above
Supported Protocols IPv4, HTTP, TCP, RTSP, RTP, ICMP, UDP, IGMP, RTCP, FTP, DNS, DHCP, ARP
Network interface RJ-45,100BASE-TX/10BASE-T, FULL/HALF/Auto negotiation
Surveillance Protocol ONVIF compatible (pass compliance test tool)
Onboard Storage SDHC Memory Card (class 10 suggested)
Electrical
Power Supply PoE IEEE 802.3af Class 0, DC12V, AC24V PoE IEEE 802.3af Class 0, AC24V
Power Consumption PoE 0.13A, DC12V 550mA PoE 0.15A, AC24V 800mA
Mechanical
Dimensions (without protrusions)
56mm (H) x 68mm (W) x 125mm (L)
(2-1/4" (H) x 2-11/16"(W) x 4-15/16" (L))
Ø 126mm x 106mm (5" x 4-3/16") Ø 155mm x 112.7mm (6-1/8" x 4-7/16")
Weight 390g (0.86lb) 490g (1.1lb) 1360g (3.0lb)
Connectors
Power Input: [VN-T16U] Spring terminal [VN-T216U/T216VPRU] removable terminal block
Network: RJ45 connector Audio In/Out: removable terminal block Alarm In/Out: removable terminal block
Environmental
Dust/Water Protection – IP66
Vandal Protection – Vandal proof [50J]
Operating Temperature -10°C to 50°C (14°F to 122°F)
Operating Humidity 0% to 90%
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Printed in Japan
VEC-0337 VN-T16U/VN-T216U/VN-T216VPRU 2012/9
All brand or product names may be trademarks and/or registered trademarks of their respective owners.
Copyright © 2012, JVCKENWOOD Corporation
DISTRIBUTED BY
Specifications
Dimensions
Unit: mm
VN-T16U VN-T216U VN-T216VPRU
Design and specifications subject to change without notice.
