JVC VN-T216 User Manual

39
Users can choose recording conditions between Event and Network Loss. When
users select “Event”, 2 more selections will be effective and Recording Time can be
selectable in 5s, 10s, 15s, 20s, 25s, 30s, 35s, 40s, 45s, 50s, 55s or 60s.
SD Free Capacity
It shows the free capacity of the SD card.
Note
 H.264 is the preferred source for recording.
 If both Encoder No.1 and Encoder No.2 are H.264, the stream
will choose the Encoder No.2 as recording source.
 If Encoder No.1 is 1080P or 720P, SD recording can be
enabled only when user choose the following 5 combinations.
NO.
Encoder No.1
Encoder No.2
1
H.264 1080p
No streaming
2
H.264 720p
H.264 D1
3
H.264 720p
H.264 QVGA
4
H.264 720p
No streaming
5
MPEG4 720p
No streaming
Notes of SD memory card:
FAT32 format is available.
After stopping record, eject SD memory card.
Keep power during SD recording.
Cheap SD memory cards are not reliable. Expensive SD memory cards are
recommended for data safety.

JVC VN-T216 Specifications

General

Resolution	700 TVL
Sensor Type	1/3" CCD
Lens	3.6mm Fixed
Weatherproof Rating	IP66
Horizontal Resolution	700 TVL
Power Supply	DC 12V
S/N Ratio	More than 50dB
Operating Temperature	-10°C to +50°C
IR Range	65ft (20m)
