Technical specifications:
VL 8 (8”+1”) VL 10 (10”+1”) VL 12 (12”+1”) VL 15 (15”+1”)
Nominal load /
Program load
250 / 500 W 350 / 700 W 350 / 700 W 400 / 800 W
Impedance
(Ohm)
8 8 8 8
Frequency
range
75 Hz - 19 kHz 60 Hz - 19 kHz 60 Hz - 19 kHz 55 Hz - 19 kHz
Crossover
freuquency
2000 Hz 2000 Hz 2000 Hz 2000 Hz
Dispersion
(h x v)
85° x 55°
(elliptical)
85° x 55° (elliptic.)
rotatable horn
75° x 45°
(bir-adial)
75° x 45°
(bi-radial)
SPL nominal 95 dB (1 W / 1 m) 96 dB (1 W / 1 m) 98 dB (1 W / 1 m)
100 dB
(1 W / 1 m)
SPL max.
119 dB
Nominal load AES
121 dB
Nominal load AES
123 dB
Nominal load AES
126 dB
Nominal load AES
Connectors
2 x Speakon NL 4
(1+/1-) / (2+/2-)
2 x Speakon NL 4
(1+/1-) / (2+/2-)
2 x Speakon NL 4
(1+/1-) / (2+/2-)
2 x Speakon NL 4
(1+/1-) / (2+/2-)
Features
side-mounted
handle, swivelling
flange with variable
tilt angle +/- 20°,
2 x M8 treads
side-mounted
handle, swivelling
flange with variable
tilt angle +/- 20°,
2 x M8 treads
side-mounted
handle, swivelling
flange with variable
tilt angle +/- 20°,
2 x M8 treads
2 side-mounted
handles, swivelling
flange with variable
tilt angle +/- 20°,
2 x M8 treads
Dimensions in
mm (W x H x D)
280 x 460 x 245 330 x 580 x 340 390 x 610 x 360 445 x 700 x 425
Weight 9 kg 14 kg 15 kg 20 kg
System-
extension
(recommen-
dation)
system amplifier:
SMA 2000,
DA 428
passively
channelled:
VB 15 t, VB 15 w
actively
channelled:
VB 15, VB 215
system amplifier:
SMA 2000,
DA 428
passively
channelled:
VB 15 t, VB 15 w
actively
channelled:
VB 15, VB 215,
VB 18
system amplifier:
SMA 2000,
DA 428
passively
channelled:
VB 15 w, VB 18 w
actively
channelled:
VB 15, VB 215,
VB 18
system amplifier:
SMA 2000,
DA 428
passively
channelled:
VB 18 w
actively
channelled:
VB 215, VB 18
Optional
accessories
protective cover,
universal mounting
plate with TV
spigot
protective cover,
universal
mounting plate
with TV spigot
protective cover,
universal
mounting plate
with TV spigot
protective cover,
universal
mounting plate
with TV spigot
