Cluster- installation VL 10 i:
Its sophisticated symmetrical cluster design allows the construction of horizontal and
vertical speaker combinations using up to 9 elements (360°) which can be easily fitted
together with the available mounting plates. The housing is angled by 20° per side to
achieve a good acoustic coupling of two systems beside each other in high frequencies.
This ensures a wide and consistent sound dispersion within a wide frequency range.
80°
120°
160°
vertical or horizontal cluster-installation
Connection panel VL 12 i :
signal at 1+/1-; please tight the
connection clamps appropriately
