K.M.E. VERSIO VL 8 - Page 31

31
Technical specifications:
VB 15 w (15“) VB 18 w (18“)
Nominal load /
Programm load
500 / 1000 W 500 W / 1000 W
Impedance (Ohm) 4 4
Frequency range 40 Hz – 130 Hz (fx) 38 Hz – 130 Hz (fx)
SPL nominal 100 dB (1 W / 1 m) 100 dB (1 W / 1 m)
SPL max. 127 dB Nominal load AES 127 dB Nominal load AES
Connectors
2 x Speakon NL 4
(1 x in + 1 x out top unit 8 Ohm)
2 x Speakon NL 4
(1 x in + 1 x out top unit 8 Ohm)
Features
2 side-mounted handles,
M20 fixing plate,
stacking elements
2 side-mounted handles,
M20 fixing plate,
stacking elements
Dimensions in mm
(W x H x D)
460 x 515 x 500 520 x 610 x 525
Weight 26 kg 29 kg
System extension
(recommendation)
system amplifier:
SMA 2000, DA 428
passively channelled:
VL 8 - VL 8 i, VL 10 i,
VL 12 - VL 12 i
system amplifier:
SMA 2000, DA 428
passively channelled:
VL 10 i, VL 12 - VL 12 i
Optional accessories protective cover protective cover
Optional accessories:
Protective covers:
VB 15 (no.2-311-052)
VB 18 (no.2-311-053)
