32
Technical specifications:
VB 15 t (15“ twin coil) VB 215 (2 x 15“)
Nominal load /
Programm load
2 x 400 W / 2 x 800 W 1000 W / 2000 W
Impedance (Ohm) 2 x 4 4
Frequency range 40 Hz – 130 Hz (fx) 40 Hz – 800 Hz (fx)
SPL nominal 100 dB (1 W / 1 m) 104 dB (1 W / 1 m)
SPL max. 127 dB Nominal load AES 134 dB Nominal load AES
Connectors
4 x Speakon NL 4
(2 x in + 2 x out top unit 8 Ohm)
2 x Speakon NL 4
(1+/1-) / (2+/2-)
Features
2 side-mounted handles,
M20 fixing plate,
stacking elements
2 side-mounted handles,
9 x M10 treads,
stacking elements
Dimensions in mm
(W x H x D)
460 x 515 x 500 1010 x 460 x 495
Weight 32 kg 41 kg
System extension
(recommendation)
system amplifier:
SMA 2000, DA 428
passively channelled:
VL 6 i, VL 8 - VL 8 i
system amplifier:
SMA 2000, DA 428
actively channelled:
VL 8 - VL 8 i, VL 10 i,
VL 12 - VL 12 i, VL 240, VL 250
Optional accessories protective cover M10 eyebolts (no.4-240-305)
