Dimensions—Mounting Template
Wall Plate
3/4"
(1.9 cm)
KI-00580E-06-16
4 3/4"
(12 cm)
3"
(7.6 cm)
TOP
5
Dimensions—Mounting Template
Mullion
1 11/16"
(4.49 cm)
TOP
3/4"
(1.91 cm)
4 7/16"
(11.5 cm)
KI-00581E-06-16
