Kaba MIFARE User Manual

Device description
k4evo707en-2012-07 13
2.3 MIFARE/LEGIC module
2.3.1 Anti-collision (several badges in the field)
If the Compact Reader detects more than one badge with the same technology
(ISO 14443A or ISO 15693), it either reads nothing at all or selects one badge at random.
2.3.2 Overview of supported RFID technologies with possible media applications
IMPORTANT
The table below shows which RFID technologies and media applications are supported.
An X indicates where this applies to at least one of the firmware options.
The corresponding chapters describe what the various firmware options support
(see also Chapter 1 / Page 7)
.
Supported RFID technologies
MIFARE
DESFire
MIFARE
Classic
LEGIC
advant
LEGIC
prime
Supported RFID standard
MIFARE ISO 14443A MIFARE ISO 14443A LEGIC ISO 14443A LEGIC ISO 15693 LEGIC RF
Media applications:
Unique number (UID) X X X X X
Safe UID X X X X X
Card ID X X X X
Kaba Group Header X X X
Kaba advant ID X X
LEGIC access™ (advant) X X
LEGIC access™ pool (prime) X
CardLink 1.1
• Data
• Actuator status
• Media traceback
X
X
X
X
X
X
X
X
X
X
CardLink 1.0
• Data incl. actuator status
X
Other media numbers X X X X X
2.3.2.1 MIFARE
Anything that can be defined in Kaba Media Manager is also evaluated by the system. MIFARE
DESFire or MIFARE Classic media with different media applications can be read and written to by
the same Compact Reader MIFARE.
Explanations and programming options for Kaba Media Manager can be found in documentation
CM_KabaMediaManager
2.3.2.2 LEGIC
LEGIC prime or LEGIC advant media with different media applications can be read and written to
by the same Compact Reader LEGIC (LEGIC advant media can only be written to with LEGIC
advant components).
Dual chip card
Dual chip card with LEGIC advant (14443 A) and CardLink LEGIC prime (LEGIC RF) is supported
