Kaba MIFARE User Manual

Device description
20 k4evo707en-2012-07
2.6 Technical data
Mechanics
Mounting
 In indoor or secured outdoor area
 Flush cable mounting with rear panel or
surface cable mounting with spacer frame
 Direct mounting on metal or neutral base, can be changed over
Housing
Spacer frame/rear panel:
 Material: PC-ABS
 Color: RAL 9005, jet black, silk matt
Frame:
 Material: PC-ABS
 Color: RAL 9006 white aluminum, matt; NCS S2502-B
Front:
 Material: PMMA
 Color: RAL 9005, jet black, mirrored
Dimensions
 Compact Reader incl. rear panel: 88.5 x 88.5 x 19.4 mm (L x W x H)
 Compact Reader incl. spacer frame: 88.5 x 88.5 x 26.4 mm (L x W x H)
Connections
 quickwire™
All of the wiring is located on the mounting plate. The connections are
established with screw terminals.
Power supply
Input voltage,
without external wiring
 12 … 27 V AC, 50/60 Hz
 10 ... 34 V DC
 Power consumption: typically 1.2 W; max. 2.2 W
Interfaces
HF RFID
 Integrated antenna
RS-485 For connection to the parent control unit
Firmware Option Access Manager
 KCP protocol; galvanic isolated, 2-wire
 Baud rate 19200, 8 data bits, even parity, 1 stop bit
 Terminating resistor for bus or star-shaped wiring
Firmware Option Subterminal and Firmware Option cDML
 BPA/9 Subset protocol; galvanic isolated, 2-wire
 Automatic baud rate detection (19,200/9,600 bauds)
 7 data bits, even parity, 1 stop bit
 Terminating resistor for bus or star-shaped wiring
Programming interface For firmware updates or programmer connection
Inputs and outputs
2 binary inputs
 Max. 5 V DC
 With internal power supply and common ground, for connection of
insulated switches
 Line monitoring (can be switched off)
1 relay output
 Changeover contact: max. 34 V DC/60 W or max. 27 V AC/60 VA
 Cycles of operation at 30 V DC/1A typically 500,000
(VdS 2358 requirement is 200,000)
 Cycles of operation at 30 V DC/2A typically 100,000
