Kaiser Baas Revo - Product Diagram; Display Panel Diagram

7
EN
PRODUCT DIAGRAM
DISPLAY PANEL DIAGRAM
Green Battery Icon - Revo Glider is charged
Flashing green Battery Icon - Revo Glider is reaching low-battery
Red Battery Icon - Revo Glider has low-battery
Green Operating Icon - Revo Glider is ready to ride
Red Operating Icon - Revo Glider has encountered at error
A
Fender
D
Engine & Tyres
G
Charging Port
B
Foot Pad Sensors
E
LED Indicators
H
On/O Button
C
Display
F
Underbody Protection
A
B
C
D D
E E
F
B
G H
