Operating the rear derailleur shiing lever
Lever a: Shi to a larger sprocket.
Lever a engages in positions 1, 2 and 3.
Lever
a
Starting posi-
tion of lever
a
1. Click-in position
1. Shiing up one gear to
next larger sprocket.
Example: shiing om
3rd to 4th gear
2. Shiing up two gears
to a larger sprocket.
Example: shiing om
3rd to 5th gear
3. Shiing up three gears
to a larger sprocket.
Example: shiing om
3rd to 6th gear
2. Click-in position
3. Click-in position
Lever b: Shi to a smaller sprocket. Press lever b once to
change to the next sprocket down (smaller).
Lever
b
Starting position
of lever
b
1. Shiing up one gear to
next smaller sprocket.
Example: shiing om
4th to 3rd gear
When lever a is pressed, lever b moves with it. How-
ever, you should avoid putting any pressure on lever b
in doing so. The same applies for lever a when press-
ing lever b. The gear will not change if both levers are
operated at the same time.
Operating the ont derailleur lever (standard)
Lever a: Shi to a larger chainring
Lever
a
Starting position
of lever
a
Gear shi com-
plete stroke
Actual pull
If the lever movement does not eect a ll changeover of chainring,
press the lever repeatedly by the amount (X') to move the lever the
remaining distance (X) and change gears.
Lever
b
Starting position
of lever
b
Gear shi complete
stroke
Click-in position
Click-in position
Lever b: Shi om intermediate chainring to smallest chainring
When lever a is pressed, lever b moves with it. However,
you should avoid putting any pressure on lever b in doing
so. The same applies for lever a when pressing lever b.
The gear will not change if both levers are operated at the
same time.
