1. Oil level indicator
2. Working mode indicator
3. Overload indicator
4. Multifunctional engine switch
5. Grounding
6. 2x16A AC outlets
1. Multifunctional LED-display with overload indicator,
voltage indicator, oil level indicator
2. Economy mode switch (ЕCОN)
3. Engine start button
4. 12V DC fuse
5. Multifunctional engine switch
6. Grounding
7. 12V/8A DC outlet
8. 2x16A AC outlets
8. Ventilation grille
9. Muffler
10. Carburetor
11. Air filter
12. Spark plug
13. Maintenance cover
(for motor oil change)
MODEL KSB 30MODEL KSB 30ii S CONTROL PANEL S CONTROL PANEL
MODEL MODEL KSB 40KSB 40iЕiЕ S S CONTROL PANELCONTROL PANEL
88
99
1010 1313
1111
1212
11 1122 22 33
44
33 44
55 66 5566 88 77
Manufacturer reserves the right to make changes and/or improve-
ments in design, components set and technical attributes without
notice and without incurring obligation. The pictures in this man-
ual are schematical and may not match the parameters of original
product.
