KANEXPRO SDI-SDHDXPRO
7 | Page
1080 [50p,60p]
●
○
○
●: LED ON
○: LED OFF
! NA:
Specifications
DESCRIPTION
Support Video Resolution
SD – 720 x 480i / 720 x 576i
HD– 1280 x 720 50p/60p
1920 x 1080 50i/60i
1920 x 1080 24p/25p/30p
3G– 1920 x 1080 50p/60p
SDI format
SD-SDI (SMPTE 259M)
HD-SDI (SMPTE 292M)
3G-SDI (SMPTE 424M / SMPTE 425M)
Audio Support
2 Channel of Stereo
Re-clock Function
Yes (Dip Switch)
Coaxial Cable Type
RG6/RG59(75Ω)
Cable Equalization
3G: 100m of RG6/ 86m of RG59
HD: 170m of RG6/ 120m of RG59
SD: 400m of RG6/ 280m of RG59
*1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275 Cable
*2 Cable Length Performance: Depending on SDI Signal and
Cable Quality
Firmware Updates
Via USB
Input
1 x BNC [SDI]
Output
1 x HDMI
2 x BNC [SDI]
BNC Connector
3G 75 Ω inter-locked socket
HDMI Connector
TYPE A [19-pin female]
DIP Switch
3-pin [Re-clock / LED mode / NA]
Housing
SECC
Dimension
L:104mm x W:63.3mm xH:26mm
Power Source
Power Adapter: AC 100 ~ 240 V/DC (+6 ~ 15 V)
Operation Temperature
0~50°C [32~114°F]
Storage Temperature
-20~+60°C
