Assembly InstructionsAva
17
Step 1: Cabinet Shell
Y2
F1
5
⁄
8
“ Cam Cover x2
c2
Attach Panel Y2 to Panel F1 as shown, inserting
cam bolts into cam locks, tightening, and applying
c2 Cam Covers.
