Kangaroo Ava 9301B - Assemble Panels 01, 02, 03, 04

Assembly InstructionsAva
6
Step 1: Cabinet Shell
6x35 Cam Bolt X9
c1
8x30 Dowel Pin x34
d1
5
⁄
8
“ Cam Cover x6
c2
O3
O4
O2
O1
O1
O2
c1
d1
X3
X3
Prepare Panels O4, O3, O2 and O1
as shown.
NOTE: Repeat twice for Panels O1
and O2 (3 panels total each).
X3
Attach Panel O1 to Panel O2 by inserting
cam bolts into cam locks as shown.
Tighten cam locks and apply c2 Cam
Covers.
