Rear Wheel Assembly and Removal
Both rear wheels on your X-Series may be easily removed and replaced. Wheels are held in place by a spring-loaded
release tab on the inside of each wheel. The tab seats into a groove on the axle. There is a groove for the Drive
position and one for Free-Wheeling Mode.
To install the wheel on the axle, pull the wheel release tab back. (Figure 20) While holding the release tab, place
the wheel on the end of the axle. Slip wheel all the way against the hub, aligning the drive pins on the hub into the
drive holes in the wheel. When the wheel is on the axle, against the hub with drive pins engaged, release the tab.
(Figure 21) This will allow the release tab to lock into the Drive groove, and the wheel should now be securely
mounted on the axle. Wheels should NOT slide off the axle. To remove the wheels, pull the release tab back toward
the tire and slide the wheel off axle. Wheels are not left/right specic and can be installed on either side.
