Step 6: Drawer Accessories
Drawer Insert Runners x2
s6
3.5x30 Screw x6
Magnet x1
Catch Plate
x0
m
3.5x14 Screw x2
s1
Threaded Dowel Pin x3
p
6x50 Dowel Pin x41
d2
Knob x2
h1
4x20 Fix Bolt x2
b2
3M Clear Adhesive
Panel Protector x4
L4
L4
A3
p
m
s1
h1
b2
d2
O8
O8
Attach Drawer Insert
Runners to each
L4 Panel, using s6
Screws as shown.
Attach m Magnet
to Panel A3, using s1
Screws.
Attach h3
Knobs to Panel
O8, using b2
Fix Bolts.
Attach
d2 Dowel
Pins.
Flip Panel O8 over and
apply Clear Adhesive
Panel Protectors.
Screw in 3 p Threaded Dowel Pins.
