Kangaroo Sydney - Page 30

Assembly InstructionsSydney XL
30
Step 6: Drawer Accessories
6x35 Cam Bolt x8
c1
5
⁄
8
“ Cam Cover x8
c2
L4
L4
L4
L4
L4
L4
L5
L5
L5
L5
L5
Attach 4 c1 Cam Bolts to each Panel L4.
Attach the two L5 Panels
to Panel L4 as shown.
Tighten cam locks and
apply cam covers.
Attach the re-
maining L4 Panel
to the L5 Panels
as shown, sliding
drawer bottom into
the groove.
Tighten cam locks and
apply cam covers.
L6
L6
L5
