Step 5: Drawers
5
⁄
8
“ Cam Cover x4
c2
Handle x1
h
4x20 Fix Bolt x2
b2
h
b2
Fully extend the cabinet rails, align drawer rails
and slide drawers into cabinet.
Be sure that the silver ball bearing pieces
are positioned all the way to the front of
the rails.
TIP: Gently open and close the drawers a few
times to engage the Soft Close mechanism.
For further help, visit
www.arrowsewing.com/assembly
and scroll down for helpful videos.
Slide drawer bottom L7
down into the grooves
on Panels L2, L3 and
Panel L1 as shown.
L3
L2
L7
L1
Attach drawer front Panel L to drawer
side Panels L3 and L2 as shown, slid-
ing drawer bottom L7 into the groove
on Panel L. Then attach h Handle with
b2 Fix Bolts.
Tighten cams and cover
with c2 Cam
Covers.
L3
L2
L
