Assembly InstructionsSydney XL
9
Step 1: Cabinet Shell
5
⁄
8
“ Cam Cover x2
NOTE: The illustrations shown through Page 11 show upside down assembly.
Assembling these panels upside down will make attaching the bottom
(Panel G) easier.
Once the bottom is attached, you will flip the cabinet over.
You may need a second person to help you.
Attach Panel Y2 to Panel D as shown.
Tighten Cam Locks and apply Cam Covers.
To Next Page
