Assembly InstructionsSydney XL
8
Step 1: Cabinet Shell
8x30 Dowel Pin x4
d1
d1
O5
O6
Y2
O5
O6
5
⁄
8
“ Cam Cover x4
c2
Install 2 d1 Dowel Pins in Panel O6.
Install 2 d1 Dowel Pins in Panel O5.
Attach Panels O6 and O5 to Panel Y2.
Tighten cam locks and apply cam covers.
