Service and Repair Manual
Model 710/760
TORQUE SETTINGS
SERVICE TOOLS
All repairs may be completed with standard workshop tools and equipment.
MODEL 710/760
ITEM NO. PART NO. DESCRIPTION NM IN/LBS.
2 9170 3282 20 SCREW 1.8 19
4 9170 3284 70 PIVOT BOLT 2.8 25
17 9170 3284 10 SCREW 4 35
22 9170 7040 03 SCREW 1.8 16
31 9170 7040 02 SCREW 1.8 16
36 9170 0198 60 SCREW 4 35
50 9170 7040 04 SCREW 2 18
54 9170 7040 07 SCREW 3 27
710BV/KV
86 9170 3290 60 SCREW 15 133
101 9170 3278 60 SCREW 10 89
710MV
87 9170 3290 60 SCREW 10 89
100 9170 3278 60 SCREW 10 89
760KV/SV
103 9170 3290 60 SCREW 15 133
109 9170 3278 60 SCREW 10 89
760MV
115 9170 3290 60 SCREW 15 133
147 9170 7030 02 SCREW 0.7 6
Service and Repair Manual
Model 710BV/KV/MV/760KV/SV/MV
