Supplied Parts and Hardware
3
Wall Plate
A: M5 x 15mm
Screw
C: M6 x 15mm
Screw
B: M5 x 25mm
Screw
D: M6 x 25mm
Screw
E: M8 x 20mm
Screw
G: M8 x 50mm
Screw
F: M8 x 35mm
Screw
L: Lag Bolt
N: 4mm Allen Key
O: 5mm Allen Key
P: 6mm Allen Key
M: Concrete Anchor
x4
x4
x4
K: 10 mm Spacer
J: 5mm Spacer
x4
x8
x6
I: Lag Bolt Washer
x6
x6
x4 x4 x4 x4
x4
H: Washer
Q: Quick-Lock
Bracket Arm
R: Locking
Bracket Arm
Required Tools
Socket
Set
Phillips
Screwdriver
Hammer (for
Concrete
installs)
Stud
Finder
Level Drill
7/16”
Masonry
Bit
3/16”
Wood
Bit
Pencil
