ROUGHING-INROUGHING-IN
-2-
UNIT : mm
INSTALLATIONINSTALLATION
A. Install Washbasin Cabinet
Install the services.
Hot (H) and Cold (C) inlets must be connected to the correct
inlet pipes.
Install the drain in accordance with the manufacturer s
instructions.
We suggest using P-trap drain. Connect P-trap pipe with
washbasin drain.
Caution!Make sure a watertight seal exisits on all
washbasin drain connections.
Caution!Provide access to the plumbing connections
for future plumbing maintenance.
The hot and cold water supplies must be installed with
isolating valves.
A.
(H) (C)
P
