9.800-966.0-R06/07/17
SERVICE MANUAL
To locate your local Kärcher Shark Commercial Pressure Washer Dealer nearest you,
visit www.karchercommercial.com
HEATER
ON
T
IMER
—
7
DAY
CONT
R
OLA
DO
R
DE
T
IE
MP
O DE
S
IE
T
E
D
I
EAS
MINUT
E
R
I
E
D
E
7
JO
U
RS
P
OWER
CO
RR
IENTE
C
O
U
R
A
NT
H
EATER
CA
L
E
N
TADOR
C
HA
UF
F
E
-
E
A
U
P
ULL OUT
P
IN
S
TO SE
T
DES
IRE
D
“ON”
T
IME
S
E
X
T
RAIGA L
A
S
CL
AVI
J
AS
P
ARA
E
S
TABLE
C
E
R E
L
T
I
E
MPO
DE
S
EADO.
T
I
RER
L
E
S
P
O
I
N
T
E
UR
S
V
E
R
S
L
’E
X
T
E
R
I
EUR POUR
E
’T
A
BL
IR
L
E
S
H
O
RA
I
R
E
S
D’O
P
E
RAT
IO
N
10
-
07
26
O
N
P
RE
N
DE
R
O
I
OFF
AP
A
G
AR
E
T
TE
INT
.
IN
S
T
R
U
C
TION
S
4
0
°
4
0
°
2
5
°
IN
S
TR
U
C
T
IO
N
S
IN
S
T
R
U
C
C
ION
E
S
1
5
°
O
N
P
R
E
N
D
E
R
O
F
F
I
O
98009660-1
E
X
P
O
S
E
D
P
U
L
L
E
Y
S
A
N
D
B
E
L
T
S
C
A
N
C
A
U
S
E
I
N
J
U
R
Y
PR
EC
A
U
C
I
O
N/
A
V
ER
TISSEM
EN
T
W
A
R
N
I
NG
MODEL # ORDER #
HDS 4.0/20 E Ec 1.109-075.0
HDS 4.0/30 E Ec
HDS 4.0/20 E Ef
HDS 4.0/30 E Ef
1.109-076.0
1.109-956.0
1.109-957.0

Table of Contents

Questions and Answers

  • J
    Jon GonzalezSep 12, 2025
    Why Karcher Shark Pressure Washer unloader does not go into bypass or will cycle itself?
    • J
      Jennifer MaddenSep 12, 2025
      If the unloader on your Karcher Shark Pressure Washer doesn't go into bypass or cycles itself, it could be because the spray gun or hose is leaking (check and repair all leaks), the check plunger didn't move or seal (remove the discharge port, clean and inspect the check plunger, and replace the O-ring if needed), or the actuator O-ring has failed (remove the actuator plunger assembly and inspect/replace the O-ring and back-up rings).
  • A
    Alexander ObrienAug 25, 2025
    Why Karcher Shark HDS 4.0/20 E Ec has pressure low after period of normal use?
    • S
      Scott LynchAug 25, 2025
      If your Karcher Shark Pressure Washer experiences low pressure after a period of normal use, the nozzle might be worn (check and replace if necessary), the inlet or discharge valves might be blocked or worn (check, clean, or replace), or the unloader valve seat might be worn (check and replace if necessary).
  • G
    glenndwayneAug 27, 2025
    What to do if Karcher Shark HDS 4.0/20 E Ec Pressure Washer pump running normally but low water pressure?
    • E
      Erica BurnsAug 27, 2025
      If the pump in your Karcher Shark Pressure Washer is running normally but the water pressure is low, it could be due to an air leak in the inlet (check the water supply and connections for air entering) or a faulty pressure unloader (bypass the pressure unloader by wiring the spray gun open; if the PSI is good, turn off the machine and replace the regulator, but do not release the spray gun while bypassing the unloader).
  • B
    Brittany BakerAug 27, 2025
    Why Karcher Shark HDS 4.0/20 E Ec system will not start?
    • B
      Brian HernandezAug 28, 2025
      Your Karcher Shark Pressure Washer might not start due to several reasons. Ensure that the power is on, water is available, and the auto switch is activated. Check if the motor overload has tripped and reset it if necessary. Also, inspect the control fuse (2 or 3 amp) and replace it if blown. A faulty pressure switch or timer could also be the cause; inspect, clean, or replace them as needed.
  • D
    Dana Ryan DDSAug 29, 2025
    Why does Karcher Shark Pressure Washer system stop after approximately 10 seconds and then restarts?
    • L
      Lisa PerryAug 29, 2025
      If your Karcher Shark Pressure Washer stops after about 10 seconds and then restarts, it could be due to a faulty pressure switch (check and replace it) or a leak in the system (fix the leak).
  • T
    traciduncanAug 30, 2025
    What to do if Karcher Shark Pressure Washer system will not stop?
    • B
      Brandon SandersAug 31, 2025
      If your Karcher Shark Pressure Washer system won't stop, there might be a water leak in the discharge line (repair the leak), a faulty pressure switch (disconnect it at the timer; if the unit stops, replace the pressure switch), or a faulty timer resistor (replace the timer).
  • J
    Joan ShepardSep 19, 2025
    What causes excessive vibration in delivery line of Karcher Shark HDS 4.0/20 E Ec?
    • E
      everettbrittanySep 22, 2025
      Excessive vibration in the delivery line of your Karcher Shark Pressure Washer is caused by irregular functioning of the valves, so check and replace them if necessary.
  • E
    Erica ClarkNov 20, 2025
    What to do if Karcher Shark Pressure Washer has low operating pressure?
    • M
      Matthew PriceNov 20, 2025
      If your Karcher Shark Pressure Washer has low operating pressure, it could be due to several factors. First, check for a faulty pressure gauge and replace it if needed. Ensure you have a sufficient water supply, using a larger garden hose and cleaning the filter washer at the water inlet. The spray nozzle might be old, worn, or incorrect; match the nozzle number to your machine or replace it. Inspect the plumbing system for leaks and repair them with Teflon tape. If applicable, adjust the unloader valve for proper pressure or install a repair kit. Other potential issues include worn packing in the pump (install a new packing kit), fouled or dirty inlet/discharge valves (clean them), worn inlet/discharge valves (replace with a valve kit), or a leaking pressure control valve (rebuild or repl...
  • J
    Jessica WrightSep 9, 2025
    Why is water escaping from fill pipe on heat exchanger of Karcher Shark HDS 4.0/20 E Ec Pressure Washer?
    • R
      Roy GarciaSep 9, 2025
      Water escaping from the fill pipe on the heat exchanger of your Karcher Shark Pressure Washer might be due to cold water being added to the heat exchanger (this will stop once it reaches operating temperature) or a ruptured or leaking coil (check, repair, or replace the fittings).
  • N
    Nancy DaviesSep 6, 2025
    Why Karcher Shark HDS 4.0/20 E Ec system won’t come up to pressure?
    • J
      Jennifer StewartSep 6, 2025
      If your Karcher Shark Pressure Washer system won’t reach the correct pressure, it could be due to several reasons: water leaking between the ball and seat (disassemble the inlet fitting and check for contaminates or worn parts, cleaning or replacing as needed), bad O-rings on the actuator plunger (remove the actuator assembly and inspect/replace the O-rings), an improperly set locknut (readjust the locknut), an incorrect tip/GPM combination (check the actual GPM on the unrestricted pump and size the tip accordingly), a worn tip (replace it), or a bad gauge (replace the gauge).

Summary

Exploded View - Left Side

Exploded View - Right Side

Exploded View Parts List

Cabinet Exploded View - Left Side

Cabinet Exploded View - Right Side

Cabinet Parts List

Hose & Spray Gun Assembly and Parts List

Specifications

VRT3 Unloader Exploded View and Parts List

Unloader Adjustment Procedures

Step-by-step guide for adjusting the unloader valve on VRT3 models.

VB8 Unloader Valve Exploded View & Parts List

KM.3 Series Pump Exploded View

Troubleshooting

Wiring Diagram - With Auto Start;Stop

Wiring Diagram - With Time Delay Shutdown Option

Karcher Shark HDS 4.0/20 E Ec Specifications
