– 3
Caution
The device must be secured and lifted ac-
cording to the regulations EN 13155. The
device may not be lifted centrally with one
fork of the forklift.
Set the dirt container down on an even
surface.
Clean the outer surface of the dirt con-
tainer so that sufficient adhesion of the
sleeve is ensured.
Open the sleeve and place the dirt con-
tainer in the device.
A Support
B Bead
Note: Ensure that the dirt container is lifted
underneath the first bead, which is located
below the holder.
Close sleeve.
A Eyelet
B Counter-nut
C Safety lock
D Clamping lock
Adjust tension lock: Loosen the lock
nut, adjust the eye with a rotary move-
ment, retighten lock nut.
Note: Adjust the tension lock in a way that
the sleeve is in tight contact with the dirt
container.
Close the tension lock and snap in the
safety lock.
Lift the device by means of a crane or
forklift and bring it into the desired emp-
tying position.
Emptying the dirt container
B
A
CD AB
10 EN
