Kärcher 595 - SPARE - Page 9

"=> xxxxxx" = bis Werknummer / up to serial No. / jusqu' au No. de fabr. / "xxxxxx =>" = ab Werknummer / from serial No. / a partir du No. de fabr. /
2.1
KOLBEN
GRUPPE:
GROUP:
GROUPPE:
2.1
2.1
PISTON
PISTON
K 595C2
POS. BENNENNUNG TEILE-NR. STCK
ITM. DESCRIPTION PART-NO. QTY.
POS. DESIGNATION NO.PIECE NBR.
1 5.030-533.0 1FORMTEIL / MOULDED PART / PREFORME
2 5.332-209.0 1SCHRAUBENFEDER / HELICAL SPRING / RESSORT
CYLINDRIQUE
3 5.582-080.0 1VENTILTELLER / VALVE DISC / TETE DE SOUPAPE
4 6.362-097.0 1O-RING 85,0 X 3,0 / GASKET / BAQUE D'ETANCHEITE
5 5.030-500.0 3FORMTEIL / MOULDED PART / PREFORME
6 5.332-206.0 3SCHRAUBENFEDER / HELICAL SPRING / RESSORT
CYLINDRIQUE
7 5.553-175.0 3KOLBEN / PISTON / PISTON
8 6.365-322.0 3NUTRING 16X24X7 / GROOVED RING / JOINT A LEVRES
9 5.115-385.0 3SCHEIBE / WASHER / RONDELLE
10 5.115-425.0 3SCHEIBE / WASHER / RONDELLE
11 6.365-321.0 3NUTRING 16X24X4,6 / GROOVED RING / JOINT A LEVRES
12 5.060-340.0 1GEHAEUSE / HOUSING / BOITIER
13 6.304-016.0 2ZYL.SCHR. M 6X 12 / CHEESE HEAD SCREW / VIS A TETE
CYLINDR.
100 2.883-103.0 1PUMPENSET / PUMP SET / GROUPE DE POMPES
202083 01073190 59526060
