English
Control Elements
1 Handle
2 Holder for the electric cable
3 Holder for the high-pressure hose
4 Tank for cleaning agent
5 Hand screw for adjusting the handle
6 Connecting cable
7 Spray gun
8 Safety ratchet
9 High-pressure hose
10 Spray lance with pressure regulator
11 Dirt blaster
12 Coupling
13 Water connection and strainer
14 High-pressure connection
15 Cleaning agent metering valve
16 Appliance switch
17 Rotating cleaning brush
Unpacking the appliance
••
••
• If, on unpacking the appliance, it is found
to be damaged, please inform your dealer
immediately.
Fitting the accessories
••
••
• Push the spray lance against the spring into the
bayonet connector of the gun, and then rotate it
through 90 ° until it clicks into place.
Checking the oil level
••
••
• Remove the knob for the cleaning agent metering
valve. Pull the hood over the side mountings and
lift off.
••
••
• Check the oil level through the inspection window
on the high-pressure pump.
Water connection
••
••
• See Technical Data for connection values.
••
••
• Please observe specifications of your water
supply authority.
••
••
• Attach supply hose to the appliance and water
main. (Water supply hose does not form part of
standard delivery.)
••
••
• Before drawing water from an open container, set
the cleaning agent metering valve to “0”.
Always use a water supply hose with a suction
filter and a minimum diameter of 3/4".
Electrical connection
• See technical data for connection values.
• Only connect the appliance to power supply volta-
ge specified on the rating plate.
• Should the standard appliance plug not fit the
mains plug point, it should be adjusted by some-
one skilled in this field.
• First turn the appliance switch to “ 0 ” and then put
the electrical plug into the socket.
• If you use an extension cable, it must always be
completely unwound from the cable drum and it
must have an adequate cross-circuit (10 m = 2.5
mm
2
, 30 m = 4.0 mm
2
).
Applications
• The appliance is used for cleaning machines, ve-
hicles, buildings, tools etc.
• Clean facades, terraces, garden equipment with
the high-pressure cleaning jet i.e. without cleaning
agent. For stubborn dirt we recommend the dirt
blaster, available as an accessory.
• Engines must only be cleaned in locations with an
oil separator (environmental protection).
• When the appliance is used at petrol stations and
other dangerous areas, the appropriate safety
regulations must be observed.
1. Starting
