9. TECHNICAL DATA
Power Connection
Voltage ..................................................... 220-240 V -AC
Current...................................................... 1~50/60 Hz
Connected/Load ............................................... 1.6 KW
Mains Fuse ........................................................ 13 AMP
Water Connection
Supply Temperature (Max)................................ 40 °C
Supply Rate (Min) ............................................ 600 Litres per Hour
Supply Pressure (Max) ...................................... 12 bar
Supply Hose Length ......................................... 7.5 metres
Diameter ...................................... 1/2 inch
Performance Data
Max. Pressure ................................................. 100 bar
Rated Pressure.................................................. 90 bar
Flow Rate......................................................... 360 litres per hour
Detergent Intake ................................................ 25 litres per hour
Recoil Force of Hand Held Spray Gun
at Operating Pressure (Max) ............................. 12 N
Optimum Working Distance on High Pressure .. 30 cm
Unit vibrations ................................................... 0.8 m/s²
Noise L
PA
(EN 60704-1) .................................... 76 dB(A)
L
WA
(EN ISO 4871) .................................. 92 dB(A)
Dimensions
Length.............................................................. 430 mm
Width ............................................................... 145 mm
Height .............................................................. 240 mm
Weight .............................................................. 4.3 Kg
Circuit Diagram
M1 Motor
Q1 Appliance switch
S1 Pressure-operated switch
Z 1 Suppressor
