Technical specifications
Power
Nominal voltage V 25,2
Battery capacity Ah (5h) 21
Battery type Li-ion
Average power consumption W 500
Protective class - 1
Suction engine output W 280
Brush engine output W 185
Operating temperature range °C 0...40
Vacuuming
Cleaning power, air quantity l/s 20
Cleaning power, negative pressure kPa 8
Cleaning brushes
Working width mm 350
Brush diameter mm 96
Brush speed 1/min 1050
Charger
Voltage V/Hz 110...120/50...60
Power Input W 300
Dimensions and weights
Theoretical surface cleaning performance m
2
/h 1400
Fresh/waste water tank volume l 12
Permissible overall weight kg 48
Transport weight kg 36
Length x width x height mm 930x420x1100
Values determined as per EN 60335-2-72
Total oscillation value m/s
2
<2,5
Uncertainty K m/s
2
0,2
Sound pressure level L
pA
dB(A) 65
Uncertainty K
pA
dB(A) 2
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 84
16 EN
