BR/BD 75/140 R, BR/BD 90/140 R Unit Functions
Page 3 / 71
New Unit Information 03.2004
1 Steering wheel
2 Control panel
3 Cap, fresh-water tank
4 Fresh-water tank
5 Cover, main control printed circuit board
6 Central battery connector (X1)
7 Drive unit pedal
8 Front wheel, wheel hub motor
9 Lateral sealing strip, spring-loaded
10 Brush head, BR version
11 Coarse dirt pan (BR version only)
12 Seat
View from front (BR-Version)
1
3
4
6
7
8
9
12
2
5
10
11
