Kärcher DS 6 User Manual

– 10
Subject to technical modifications!
You can rectify minor faults yourself with the help of the
following overview.
If in doubt, please consult the authorized customer ser-
vice.
Power supply is interrupted
 Remove the mains plug, check the connecting ca-
ble and the mains plug for damage.
 Reinsert the baffle plate correctly.
(see: FILLING THE WATER FILTER RESER-
VOIR)
 Check the intermediate filter.
 Wash the filter, install new intermediate filter if re-
quired.
(see: CARE, MAINTENANCE)
 Let the intermediate filter dry or install new dry filter.
(see: CARE, MAINTENANCE)
 Replace the water and add 1 to 2 capfuls of Foam-
Stop. Check the intermediate filter for moisture. If
necessary, clean the damp filter under running wa-
ter and allow it to dry afterwards or install new filter.
 Check the MIN / MAX marks on the reservoir.
 Replace the HEPA filter.
(see: CARE, MAINTENANCE)
 Remove the blockage.
(see: CARE, MAINTENANCE)
 Close the false air slide.
(see: WORKING WITH THE FLOOR NOZZLE)
 Properly install the cover of the water filter contain-
er.
 Remove the water filter and correctly insert it into
the appliance.
(see: FILLING THE WATER FILTER RESER-
VOIR)
Technical specifications
Nominal voltage
1~50-60 Hz
220-240 V
Fill capacity of the water filter
reservoir
2,0 l
Weight (without accessories) 7,5 kg
Nominal width, accessories 35 mm
Eco design as per 666/2013
Energy efficiency category A
Indicative annual energy con-
sumption
28,0 kWh/a
Carpet cleaning class D
Hard floor cleaning class B
Dust emission class A
Sound power level L
WA
80 dB(A)
Rated power input 650 W
DS 6 Premium:
DS 6 Premium Mediclean:
HEPA filter H 13 class according to EN 1822 (effective
1998)
DS 6:
HEPA filter H 12 class according to EN 1822 (effective
1998)
Troubleshooting
Appliance does not vacuum
Weak/diminishing suction power
Forgot the baffle plate or not inserted correctly
Intermediate filter missing or not inserted correctly
Intermediate filter is dirty
Intermediate filter is wet
Strong foam generation in the water filter reservoir
Too little or too much water in the water filter
reservoir
HEPA filter is soiled
Accessory is blocked
False air slide at the handle is open
Appliance flap does not close
The cover of the water filter is not properly installed
The water filter is not properly installed
16 EN

Kärcher DS 6 Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	650 W
Annual energy consumption	28 kWh
Type	Cylinder vacuum
Hose length	2.1 m
Cleaning type	Dry&wet
Dust capacity	- L
Product color	Black, Yellow
Dust container type	Bagless
HEPA class	HEPA 12
Proper use	Home
Noise level	80 dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	HEPA, Water
Dirt separating method	Aqua filtering
Cord length	- m
Upholstery nozzle included	Yes

Weight and Dimensions

Depth	535 mm
Width	289 mm
Height	345 mm
Weight	7500 g
