– 12
Check that the floor head cover is correctly seated.
For this, remove the cover and then fit it back in
place.
The rollers are worn out.
Replace the rollers.
Waste water tank is overfilled.
Empty the waste water tank right away.
Waste water tank does not fit properly in the appliance.
Check that the floor head cover is firmly seated on
the waste water tank.
Check that the waste water tank flaps are correctly
closed.
ATTENTION
Do not remove the handle from the basic unit once it has
been assembled.
The handle may only be removed from the basic unit if
the unit is sent out for service purposes.
Illustration
See illustration at the end of the operating instructions
Insert screwdriver at a 90 degree angle in the small
opening at the rear side of the handle and remove
handle.
ATTENTION
Please ensure that the connection cable between the
basic unit and the handle are not damaged.
Pull carefully to avoid damaging the device.
Subject to technical modifications!
Appliance is leaking waste water.
Removing the handle from the basic unit
Technical specifications
Electrical connection
Voltage 100-240 V
1~50-60 Hz
Protection class IPX4
Device
Protective class
III
Charger protection class II
Rated power of appliance 40 W
Nominal battery voltage 7,2 - 7,4 V
Battery type Li-Ion
Operating time with full charge 20 min
Charging time for empty battery 4 h
Charger initial voltage: 9,5 V
Output current, charger 0,6 A
Performance data
Roller revolutions per minute 500 rpm
Filling quantity
Fresh water tank 360 ml
waste water tank 140 ml
Dimensions
Weight (without accessories and
cleaning fluids)
2,4 kg
Length 305 mm
Width 226 mm
Height 1220 mm
