Model G 2500 PH OVERVIEW
Item Description
1 Handle
2 Trigger gun
3 Trigger gun safety lock
4 High pressure hose
5 Gas tank
6 Spray wand
7 Dipstick
8 Water inlet with garden hose connector
Caution
Follow the maintenance instructions specified in the manual
This machine has been designed for use with cleaning detergents by the
manufacturer. The use of other cleaning detergents may affect the operation of the
machine and void the warranty.
9 High pressure outlet
10 Detergent filter
11 Spark plug
12 Hose Reel (optional) Mounting
Holes
13 Quick connect nozzles
Not pictured
- Rubber grommets (3 pcs)
