9
MAX
OIL FILLER CAP/DIPSTICK
Be sure the machine is level when checking
the oil level. (Refer to the engines operating
manual for seasonal grades).
STEP 4:
Fill gasoline tank with unleaded gasoline.
Do not use leaded gasoline. Cosult engine
manual for appropriate octane rating
Do not add oil to the gasoline.
STEP 5:
Connect the high pressure hose to the high
pressure outlet on the pump.
WARNING
High pressure hoses, ttings and couplings
are important for the safety of the appliance.
Use only hoses, ttings and couplings recom-
mended by the manufacturer.
STEP 6:
Connect garden hose to unit's water inlet
STEP 7:
Connect garden hose to the cold water source
and turn water completely on.
Do not use hot water. (Water supply tem-
perature must not exceed 104°F/40°C).
STEP 1:
Pull the spring-loaded collar of the wand back
to insert your choice of quick connect nozzle.
Release the collar and push the nozzle until-
the collar clicks.
CAUTION
High pressure in nozzle area.
Risk of injury caused by improperly locked
nozzle.
▄ Make sure you hear a "click" when inserting
the nozzle tip into the wand.
▄ Pull the nozzle to make sure it is seated
properly before operating your unit.
STEP 2:
Attach the high pressure hose to the trigger
gun. Make sure to screw the hose all the way
into the trigger gun.
CAUTION
Engine shipped without oil. Before starting
engine, ll with oil. Do not over-ll. Do not run
the engine with a high or low oil level as this
can cause engine damage.
If you have further questions regarding the
engine, please refer to the engine manual
included with the unit.
STEP 3:
Check oil level. Oil level should always be
between the "FULL" and "MAX" marks on the
dipstick as shown in the picture below.
OPERATING INSTRUCTIONS
