16 English
Figure 9
Î Loosen covering nut and take off
hose.
Figure 10
Î Take out sieve.
Note
If necessary turn in screw M8 appr. 5
mm inwards and therewith pull out
sieve.
Î Clean sieve in water.
Î Push sieve inwards.
Î Put on hose.
Î Tighten covering nut firmly.
Figure 11
Î Take out detergent suck supports.
Î Clean filter in water and reinstall.
Figure 12
Î Ready a catch bin for appr. 1 Liter
oil.
Î loosen release screw.
Î Tighten release screw.
Î Fill oil slowly up to the MAX marking.
Note
Air pockets must be able to leak out.
For oil type refer to technical specifi-
cations.
Figure 2 - Pos. 3
– Fuel tank empty
Î Refill.
Figure 2 - Pos. 8
– Engine overload/overheat
Î Turn device switch on "0" and let en-
gine cool off for min. 5 minutes.
Î If malfunction still occurs, have de-
vice checked by customer service.
Î No line voltage, see "Appliance is
not running".
Figure 14
Î Check exhaust temperature limiter;
reduce it, if required.
Î Set the appliance switch to "I".
Figure 2 - Pos. 4
– Liquid softener tank is empty, due to
technical reasons a remainder stays
in the tank.
Î Refill.
– Electrodes in the tank are dirty
Î Clean the electrodes.
Figure 2 - Pos. 5
Î Set the appliance switch to "0".
Î Allow device to cool down.
Figure 14
Î Check exhaust temperature limiter;
reduce it, if required.
Î Set the appliance switch to "I".
Clean sieve in the water short-
age safe guard
Clean filter at the detergent suck
hose
Oil change.
Dispose of old oil ecologically or turn
in at a gathering point.
MALFUNCTIONS
Fuel indicator lamp glows
Indicator lamp "Ready for use"
turns off
Indicator lamp liquid softener
glows
Engine control lamp glows
