12 English
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The undersigned act on behalf and under the power of
attorney of the company management.
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Electrical connection
Voltage 230-240
1~50
V
Hz
Connected load 1,8 kW
Protection class IP X5
Protective class I
Mains fuse (slow-blow) 13 A
Water connection
Max. feed pressure 0,8 MPa
Max. feed temperature 40 °C
Min. feed volume 9 I/min
Max. Suction height 0,5 m
Performance data
Working pressure 11 MPa
Max. permissible pressure 13 MPa
Water flow rate 6,3 I/min
Max. flow rate 7,0 I/min
Detergent flow rate 0-0,3 I/min
Recoil force of trigger gun 16 N
Dimensions and weights
Length 349 mm
Width 426 mm
Height 878 mm
Weight, ready to operate with
accessories
15,3 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Unsicherheit K
<2,5
0,3
m/s
2
m/s
2
Schalldruckpegel L
pA
Uncertainty K
pA
75
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
92 dB(A)
Subject to technical changes.
EC Declaration of Conformity
Product: High pressure cleaner
Type: 1.180-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2004/108/EC
2000/14/EC
2011/65/EU
Applied harmonized standards
EN 50581
EN 55014–1: 2006+A1: 2009+A2: 2011
EN 55014–2: 1997+A1: 2001+A2: 2008
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006+A1: 2009+A2: 2009
EN 61000–3–3: 2013
EN 62233: 2008
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 89
Guaranteed: 92
Winnenden, 2015/03/01
CEO
Head of Approbation
