– 10
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service center.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The signatories act on behalf of and with of the authority
of the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Electrical connection
Voltage 230
1~50
V
Hz
Connected load 3,0 kW
Protection class IPX5
Protective class I
Mains fuse (slow-blow) 16 A
Maximum allowed net impedance 0,394
+ j0,246
Ω
Ω
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 60 °C
Min. feed volume 12 l/min
Max. Suction height 0,5 m
Performance data
Working pressure 15 MPa
Max. permissible pressure 18 MPa
Water flow rate 9,2 l/min
Max. flow rate 10 l/min
Detergent flow rate 0,3 l/min
Recoil force of the trigger gun 27 N
Remote module SRD
Frequency 868,7-
869,2 MHz
Transmission power ERP 0,53 mW
Dimensions and weights
Length 463 mm
Width 330 mm
Height 667 mm
Typical operating weight 19,3 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
1,3
0,6
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
79
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
95 dB(A)
Reason for exception according to regulation (EU)
2019/1781 Annex I Section 2 (12): (j)
Subject to technical changes.
Warranty
EU Declaration of Conformity
Product: High pressure cleaner
Type: K 7 Full Control Plus
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2014/53/EU
2011/65/EU
2000/14/EC
2009/125/EC
Applied regulations
(EU) 2019/1781
Applied harmonized standards
EN 60335–1
EN 60335–2–79
EN 62233: 2008
EN 300 220-2 V3.1.1
EN IEC 63000: 2018
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 92
Guaranteed: 95
Winnenden, 2021/06/01
Chairman of the Board of Management
Director Regulatory Affairs & Certification
16 EN
