24 English
Use only original KÄRCHER spare parts.
You will find a list of spare parts at the end
of these operating instructions.
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Spare parts
Warranty
Technical specifications
Electrical connection
Voltage 220
1~50
V
Hz
Connected load 1,6 kW
Protection class IP X5
Protective class I
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 8 I/min
Performance data
Working pressure 9 MPa
Max. permissible pressure 12 MPa
Water flow rate 5,5 I/min
Max. flow rate 6,0 I/min
Detergent flow rate 0,3 I/min
Recoil force of trigger gun 10 N
Dimensions and weights
Length 285 mm
Width 331 mm
Height 563 mm
Weight, ready to operate
with accessories
10,7 kg
Subject to technical changes.
