Kärcher K4 User Manual

Use this pressure washer for private households only:
– for cleaning machines, vehicles, buildings, tools,
facades, terraces, gardening tools, etc. by means
of a high-pressure water jet (if necessary, with ad-
ditional cleaning agents).
– with accessories, replacement parts and cleaning
agents approved by KÄRCHER. Please observe
the information accompanying the cleaning agents.
Notes about the ingredients (REACH)
You will find current information about the ingredients
at:
www.kaercher.com/REACH
Illustrations on Page 15
Mount loose parts delivered with appliance prior to start-
up.
You will need the 2 included screws as well as a Philips
screwdriver PH 2.
Illustration
 Insert base.
 Insert the included dowels all the way into the
holes.
 Secure the base with the enclosed screws.
Illustration
 Hook in storage for spray lances.
 Secure the storage for the spray lances by means
of two screws.
Illustration
 Attach the transport handle.
 Secure the transport handle by means of two
screws.
Illustration
 Hook the net into the hooks shown in the illustra-
tion.
 Park the appliance on an even surface.
Illustration
 Put the high-pressure hose through the hose guide
from the back.
Illustration
 Push the high pressure hose into the trigger gun
until it locks audibly.
Note: Make sure the connection nipple is aligned
correctly.
Check the secure connection by pulling on the high
pressure hose.
 Unwind the high pressure hose from the hose
drum.
 Insert the mains plug into the socket.
For connection values, see type plate/technical data.
ATTENTION
Impurities in the water can damage the high-pressure
pump and the accessories. For protection, the use of
the KÄRCHER water filter (optional accessory, order
no. 4.730-059) is recommended.
Observe regulations of water supplier.
ATTENTION
Hose couplings made of metal with aquastop can dam-
age the pump! Please use plastic couplings or KÄRCH-
ER brass couplings.
Illustration
 Screw the coupling element to the water connec-
tion on the appliance.
 Attach the water supply hose to the coupling on the
water connection.
 Connect the water supply hose to the water supply.
 Completely open the water tap.
This high-pressure cleaner is suited to work with the
KÄRCHER suction hose with backflow valve (Optional
accessory, order no. 2.643-100) to draw in surface wa-
ter, e.g. from water butts or ponds (see specifications for
max. suction height).
Note: With vacuuming operation, the coupling for the
water connection is not required.
 Fill the suction hose with water.
 Screw the suction hose into the water connection of
the appliance and insert it into the water source
(e.g. rainwater drum).
Bleed the device as follows prior to operation:
 Turn on the appliance “I/ON”.
 Unlock the lever of the trigger gun.
 Push the lever of the trigger gun, the device will
switch on.
 Let the device run (max. 2 minutes) until the water
exits the trigger gun without bubbles.
 Release the lever of the trigger gun.
 Lock the lever of the trigger gun.
Proper use
Environmental protection
The packaging material can be recycled. Please
arrange for the environmentally appropriate dis-
posal of the packaging.
Old appliances contain valuable recyclable mate-
rials that should be recycled properly. Batteries
and accumulators contain substances that must
not enter the environment. Please dispose of old
devices and batteries or accumulators in an envi-
ronmentally friendly way.
Cleaning operations which produce oily waste wa-
ter, e.g. engine washes, underbody washes, may
only be carried out using washing stations
equipped with an oil separator.
Work with detergents must only be performed on
liquid-tight work surfaces with a connection to the
sewer system. Do not let release detergent into
waters or earth.
The extraction of water from public waters is pro-
hibited in some countries.
Assembly
Installing the base
Install storage for spray lances
Install the transport handle
Attach the net to the accessory compartment
Start up
Water supply
Water supply from mains
Drawing in water from open reservoirs
8 EN

Kärcher K4 Specifications

General

Form factor	Upright
Hose length	7.62 m
Power source	Electric
Product color	Black, Yellow
Pressure range	High-pressure
Variable power	Yes
Maximum flow rate	1135.62 l/h
Working pressure (max)	131 bar
Maximum input water temperature	- °C
Surface cleaner	-

Weight and Dimensions

Depth	396 mm
Width	306 mm
Height	872 mm
Weight	12020 g
