We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Electrical connection
Voltage 230
1~50
V
Hz
Connected load 2,1 kW
Protection class IP X5
Protective class I
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 0,8 MPa
Max. feed temperature 40 °C
Min. feed volume 10 I/min
Max. Suction height 0,5 m
Performance data
Working pressure 12,5 MPa
Max. permissible pressure 14,5 MPa
Water flow rate 7,5 I/min
Max. flow rate 8,3 I/min
Detergent flow rate 0,3 I/min
Recoil force of trigger gun 20 N
Dimensions and weights
Length 344 mm
Width 396 mm
Height 875 mm
Weight, ready to operate with
accessories
14,0 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
<2,5
0,3
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
71
2
dB(A)
dB(A)
Sound power level L
WA
+ Un-
certainty K
WA
86 dB(A)
Subject to technical changes.
EC Declaration of Conformity
Product: High pressure cleaner
Type: 1.180-xxx
Relevant EU Directives
2000/14/EC
2004/108/EC
2006/42/EC (+2009/127/EC)
2011/65/EU
Applied harmonized standards
EN 50581
EN 55014–1: 2006+A1: 2009+A2: 2011
EN 55014–2: 1997+A1: 2001+A2: 2008
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006+A1: 2009+A2: 2009
EN 61000–3–3: 2008
EN 62233: 2008
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 84
Guaranteed: 86
Winnenden, 2014/02/01
CEO
Head of Approbation
24 EN
