English 15
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Connected load 1,8 kW
Type of protection IPX5
Protective class II
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 8 l/min
Performance data
Working pressure 11 MPa
Max. permissible pressure 13 MPa
Water flow rate 5,2 l/min
Max. flow rate 7,0 l/min
Detergent flow rate 0,3 l/min
Recoil force of the trigger gun 13 N
Dimensions and weights
Length 297 mm
Width 310 mm
Height 865 mm
Weight, ready to operate with
accessories
7,1 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
<2,5
0,7
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
76
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
92 dB(A)
Subject to technical changes.
EU Declaration of Conformity
Product: High pressure cleaner
Type: KHD 4 L
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2014/30/EU
2011/65/EU
2000/14/EC
Applied harmonized standards
EN 60335–1
EN 60335–2–79
EN 62233: 2008
EN 55014–1: 2017
EN 55014–2: 2015
EN 61000–3–2: 2014
EN 61000–3–3: 2013
EN IEC 63000: 2018
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 89
Guaranteed: 92
Winnenden, 2021/01/01
Chairman of the Board of Management
Director Regulatory Affairs & Certification
