– 2
1 Pickup for floor nozzle
2 Suction hose
3 Air outlet, working air
4 Suction head
5 Suction head lock
6 Dirt receptacle
7 Steering roller
8 Recessed grip
9 Air inlet, motor cooling air
10 Suction support
11 Socket (Ap Te L only)
12 Floor nozzle
13 Suction tube
14 Main switch
15 Button for filter shake off system
16 Carrying handle
17 Fixing eyelet
18 Hose hook
19 Float
20 Bender
21 Cartridge filter (PES)
22 Fastening nut
23 Holder for suction pipe
24 Power cord
25 Nameplate
26 Cable hook
DANGER
When the outgoing air is carried back
into the room, a sufficient ventilation
rate L in the room must be ensured. To
comply with the required limit values the
carried back volume flow must be 50%
of the fresh air volume flow (room vol-
ume V
R
x ventilation rate L
W
) at maxi-
mum. Without a specific ventilation sys-
tem the following applies: L
W
=1h
–1
.
Only persons trained in the use of the
machine and the handling of substanc-
es for which the machine is to be used
including training in the safe disposal of
the sucked-in material may use the ma-
chine.
This appliance contains harmful dust.
Evacuation and maintenance work, in-
cluding the disposal of the dust collec-
tion containers, may only be performed
by specialists who wear the appropriate
protective equipment.
Do not use the appliance without the
complete filtering system.
Please follow the safety regulations ap-
plicable to the materials that are to be
treated.
WARNING
For vacuuming, the cartridge filter must al-
ways be installed and the fleece filter bag
inserted.
WARNING
Do not vacuum without the filter elements;
otherwise, the suction motor can get dam-
aged and this can be hazardous to health
on account of increased release of fine dust
particles.
Check whether cartridge filter and
fleece filter bag have been inserted into
the appliance.
Device elements
Symbols on the machine
WARNING: This appliance contains harm-
ful dust. The emptying and maintenance,
including the removal of the dust bag, may
only be executed by trained personnel
wearing suitable protection equipment. Do
not switch on until the complete filter sys-
tem has been installed.
Cartridge filter (PES)
Order No. 2.889-219.0
Fleece filter bag
Order No. 2.889-217.0
Safety instructions
Start up
14 EN
