Technical specifications
NT 65/2 Tact²
Mains voltage V 120
Frequency Hz 1~ 60
Rated current A 15
Container capacity gal (l) 17.2 (65)
Filling quantity (liquid) gal (l) 12.7 (48)
Air volume (max.) CFM (l/s) 2x 140 (2x 66)
Negative pressure (max.) mm (kPa) 2250 (22.1)
Type of protection -- IPX4
Protective class -- I
Suction hose connection (C-DN/C-ID) in (mm) 1.6 (40)
Length x width x height in (mm) 22.5 x 19.5 x 34.5
(575 x 490 x 880)
Typical operating weight lbs (kg) 54.0 (24.5)
Max. ambient temperature °F (°C) 104 (+40)
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 73
Uncertainty K
pA
dB(A) 1
Power cord SJTOW 3x14 AWG Wb
105 °C Vw 1
Part no.: Cable
length
USA 6.650-789.0 33 ft (10 m)
