9
English
Technical data
puzzi 200 / puzzi 100
Voltage variants
115 V (1~50/60 Hz)
Power, blower motor
Suction turbine P
max
1250 W
Suction turbine P
nominal
1100 W
Air flow, max 54 l/sec.
Vacuum 22 kPa
Power, spray pump, puzzi 200
Spray pump 2 x 40 W
Spray pressure, max. 0,2 MPa
Spray quantity 2 l/min.
Unit socket, puzzi 200
Power consumption, max. 250 W
Power, spray pump, puzzi 100
Spray pump 40 W
Spray pressure, max. 0,1 MPa
Spray quantity 1 l/min.
Dimensions
Filling capacity, fresh water 10 l
Capacity, dirty water 9 l
Length 665 mm
Width 320 mm
Height 435 mm
Weight, puzzi 200 12.1 kg
Weight, puzzi 100 10.3 kg
Sound level
Conforms to DIN EN 60704-2-1 68 dB(A)
Safety class II
Mains cable
Length 7.5 m
Type H 05 VV – F 2x1
Specifications subject to change without
prior notice.
Troubleshooting
Caution:
Danger from electrical current. Pull out
mains power plug before any work is
carried out on electrical parts.
No water coming out at the nozzle
1. Fresh-water tank empty, fill it.
2. Check that the position of the coupling
of the spray and suction hose is
correct.
3. Nozzle blocked, clean it.
4. Suction filter in fresh water tank
blocked, clean it.
5. Spray pump defective, have it replaced
by a technical expert.
Spray emitted from one side only
1. Nozzle is partly blocked, clean it.
Insufficient suction power
1. Cover not on properly, put it on
properly
2. Seal on cover dirty, clean it.
3. Fluff strainer dirty, clean it.
4. Suction hose is blocked, check and
clean it.
Spray pump too loud
1. Fresh-water tank empty, fill it
Have all inspections and work carried
out on electrical
parts done by a
technical expert. For more extensive
tasks contact customer service.
