86343350 PUZZI 50/14E 31
Pump
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86190510 11-800169 3 PLUG, 1/8P, BR
2 86323550 - 1 HOSE, 47" HP 1/4-MPT X 1/4-MPT
3 86199580 250-35 1 D/B BPR 200PSI
4 86323300 - 12 WASHER, 1/4" RUBBER
5 86197270 4008 1 ADPTR, 1/4MPT X 1/4FPT BR
6 86233150 20042 2 CLAMP, 3/8 WORM GEAR
7 86197360 31016 3 ELBOW, 1/4 NPT STREET
8 86197390 31021 1 ELBOW, 1/4NPT 45D STREET
9 86240500 40095 1 HOSEBARB, 3/8MPT X 3/8HOSE 90
10 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
11 86321280 - 1 BRKT, D/P BPR
12 86274280 70161 4 SCR, 10-32 X 1-3/8 PPHMS
13 86197760 78308 1 TEE, 1/4 STREET
14 86184900 790601 1 ELBOW, 45DEG 1/4MPT x 1/2H BR
15 86270850 57026 3 NUT, 8-32 HEX NYLOCK
16 86317840 - 1 HOSE, PULSE 16” 1/4MPT X 1/4MPT
17 86010650 87018 8 WASHER, #10 X 9/16 FLAT
18 86201140 - 1 PUMP, SERIES 112V W/ CAM
19 86318390 - 1 HOSE, 1/2ID WIRE BOUND X 42"
20 86318970 - 1 MOTOR, M35, 120V, 1.5A
21 86321470 - 1 HOSE, 3/8ID WIRE BOUND X 26"
